Features
◇ Stainless steel guide rod, corrosive resistance and wear resistance.
◇ Built-in oilless bushing has good wear resistance, which enhances lifetime.
◇ Horizontal vacuum circuit design can connect with multiple level compensators.
◇ Non-rotating design ensures accurate positioning of workpiece.
Applications
◇ Small size and light spring, suitable for electronics industry.
| How to order | ||||||
| PSPE - I 10 L A4 M5M - M10 ① ② ③ ④ ⑤ ⑥ ⑦ | ||||||
| ① Series | ② Buffer style | ③ Buffer style | ④ Rotary type | ⑤ Rotary type | ⑥ Suction cup connection | ⑦ Mounting thread |
| PSPE | I- Built-in spring | 10 20 30 40 50 | Nil- Vertical rotating R - Vertical non-rotating L - Lateral rotating B - Lateral non-rotating | Nil- M5 Female thread A4 - One touch fittingφ4hose A6 - One touch fittingφ6hose | M5F - M5Female thread M5M - M5Male thread | M10 - M10×1 |
| Selection | ||||||||
| Model | Buffer stroke | Rotary type | Vacuum port connection | Suction cup connection | Mounting thread | |||
| Nil | A4 | A6 | M5M | M5F | ||||
| PSPE-I | 10 20 30 40 50 | Nil | ● | - | - | ● | ● | M10 |
| R | - | ● | ● | ● | - | |||
| L | ● | - | - | ● | - | |||
| B | - | ● | ● | ● | - | |||
◇◇Note: "●"- standard, in stock. "-"-unavailable.
